1x16 PLC FC APC Fiber Optic Splitter Cassette Box


Features

• Low excess loss
• Excellent directivity
• Good channel-to-channel uniformity
• Low PDL
• High cost-effectiveness
• High environmental and mechanical stability

  Application
• Fiber optical communication system
• Fiber optical sensors
• CATV  System
• LAN System
• WAN System
• Performance Index

  Type	Unit	1 X 4	1 X 8	1 X 16	1 X 32
  Optical Fiber diameter	um	9/125 um(smf-28)
  wavelength	nm	1260~1620
  Insertion Loss	dB	<7.0	<10.6	<14.0	<17.3
  Uniformity	dB	<0.6	<1.0	<1.5	<2.3
  PDL Loss	dB	<0.30	<0.30	<0.30	<0.30
  Directivity	dB	>55
  Return Loss	dB	>50
  Operation Temperature	ºC	-40~ +85
  Storage Temperature	ºC	-40 ~ +85
  Device Dimension	mm	4 0X 4 X 4	4 0X 4 X 4	5 0X 4 X 4	5 0X 7 X 4
  Mini-Module Dimension	mm	5 0X 7 X 4	5 0X 7 X 4	6 0X 12 X 4	8 0X20 X 6
  Module Dimension	mm	100 X 80 X 10	100 X 80 X 10	120 X 80 X 18	140 X 115 X 18

•
