2*8 Optical PLC Splitter Sc/APC Fiber Splitter

 2*8 Optical PLC Splitter SC/APC Optical Fiber SplitterDescriptionPLC Splitter is based on planar Light wave circuit technology and precision aligning process, can divide a single/dual optical input(s) into multiple optical outputs uniformly and is denoted 1xN or 2xN .PLC Splitter is applied in FTTX deployments, PON network

Featured Products

 2*8 Optical PLC Splitter SC/APC Optical Fiber Splitter

2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter
2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter

Description

PLC Splitter is based on planar Light wave circuit technology and precision aligning process, can divide a single/dual optical input(s) into multiple optical outputs uniformly and is denoted 1xN or 2xN .PLC Splitter is applied in FTTX deployments, PON networks, CATV links and optical signal distribution currently. SUNET's PLC Splitter offers superior optical performance, high stability and high reliability,meet various application requirements in different environments.

Feature

1.Low Insertion Loss
2.Low Polarization Dependent Loss
3.Wide Operation Wavelength
4.Wide Operation Temperature
5.High Stability and Reliability

Application

1.Access Network
2.Telecom/CATV
3.Active device termination
4.Local Area Networks (LANS)
5.Metro
6.Test equipment
7.Data processing network
8.Wide Area Networks (WANS)
9.FTTX

Specification

Parameter

Specification

Operating Wavelength (nm)

1260 ~ 1650

Type

1x4

1x8

1x16

2x4

2x8

2x16

1x32

2x32

1x64

Insertion Loss (dB) Max. *

<7.3

<10.5

<13.5

<7.6

<11.2

<14.5

<16.2

<18.2

<20.5

Uniformity (dB) Max.*

<0.8

<1.0

<1.5

<1.0

<1.5

<2.0

<2.0

<2.5

<2.5

PDL(dB)Max.*

<0.2

<0.2

<0.3

<0.3

<0.3

<0.4

<0.3

<0.4

<0.3

Directivity (dB)

≥55

Return Loss (dB)

UPC ≥55                   APC ≥60

Operating Temperature (°C)

-5~ +75

Storage Temperature (°C)

-40 ~ +85

Fiber length

1m or custom length

Fiber Type

Corning  SMF-28e fiber

Connector Type

Custom specified

Power Handling (mW)

300


2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter
2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter




2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter

2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter
2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter
2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter
2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter
2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter
2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter

2*8 Optical PLC Splitter Sc/APC Optical Fiber Splitter
