CWDM SWDM9 multiplexier module

Product Overview

Coarse Wavelength Division Multiplexing, 20nm Channel Space, with 5% Bi-Direction Monitor Single Fiber 9 Channels
Bi-Direction, 18 Wavelengths, 1RU 19" rack mount chassis, 2 slots

Features

  • Cost-effective CWDM technology
  • Terminates sixteen wavelengths
  • Reliable passive thin film filter WDM optical technology
  • Low optical insertion loss
  • Low-profile modular design

Applications

  • Metro Network
  • Access Network
  • FTTH Application
  • Unidirectional network traffic rings
  • Point-to-point applications
  • CATV Fiberoptic Links

Performance Specification

Parameter
UnitThin Film Coarse WDM
Channel spacingnm20
Number of Channelsch18
Central Wavelengthnm1271, 1291, 1311, 1331, 1351, 1371, 1391, 1411, 1431, 1451, 1471, 1491, 1511, 1531, 1551, 1571, 1591, 1611
Operation WavelengthnmITU±6.5
Ripple in PassbanddB0.4
Power Monitor Rate%5
Channel Insertion Loss (with connector)dB≤ 4.8
End To End Insertion Loss (with connector)dB≤ 7.0
Mux/Demux pair Insertion Loss uniformitydB≤ 2.5
Insertion Loss for Monitoring PortdB≥ 10 and ≤ 21.5
IsolationAdjacent channeldB≥ 30
Non-adjacent channeldB≥ 40
Polarization Dependent LossdB≤ 0.15
Polarization Mode dispersionps≤ 0.20
Return Loss (with connector)dB≥ 45
DirectivitydB≥ 50
Insertion Loss Temperature StabilitydB/°C≤ 0.005
Temperature Wavelength Driftnm/°C≤ 0.002
Recommend Operation Environment
Power HandlingmW500
Tensile LoadN5
Operating Temperature°C0 ~ 70
Storage Temperature°C-40 ~ 85
Relative Humidity%95
Package Specification
Fiber Type Corning SMF-28e


Connector TypeCOMSC/UPC
MONFC/UPC
CWDM channelsLC/UPC
