Description

  FAT-16A fiber access termination box is able to hold up to 16 subscribers.It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system.It integrates fiber splicing,splitting,distribution,storage and cable connection in one solid protection box.

ABS material used ensures the body strong and light.
Water-proof design for outdoor uses.
Easy installations: Ready for wall mount - installation kits provided.
Adapter slots used - No screws and tools needed for installing adapters.
Ready for splitters: designed space for adding splitters.
Space saving! Double-layer design for easier installation and maintenances:
Lower layer for splitters and over length fiber storage.
Upper layer for splicing, cross-connecting and fiber distribution.
Cable fixing units provided for fixing the outdoor optical cable.
Protection Level: IP66.
Accommodates both cable glands as well as tie-wraps
Lock provided for extra security

Feature

1.Water-proof design with IP-66 Protection level.
2.Integrated with splice cassette and cable management rods.
3.Manage fibers in a reasonable fiber radius condition.
4.Easy to maintain and extend the capacity.
5.Fiber bend radius control more than 40mm.
6.Suitable for the fusion splice or mechanical splice.
7.2 pcs of 1*8 Splitter can be installed as an option.
8.Efficient cable management.16 ports cable entrance for drop cable

Application

1.Optical LAN & WAN & CATV
2.FTTH project & FTTX Deployments
3.Broadband High-bit rate data transmission
4.Active device terminations
5.Testing instruments
6.Optical fiber communication networks
7.PON Networks
8.Optical Signal Distribution

Specification

Product  Name

FTTH Access Terminal Junction Box,16 Core

Material

PC+ABS

Dimension

295*220*85mm

Color

Black or white

Work Temperature

-40  ~+85  ºC

Relative Humidity

≤ 85% (+30  C)

Atmospheric Pressure

60Kpa~106Kpa

Weight

1.57KG

Max Capacity

SC 16 Ports



PLC1x16(SC)

Packing Quantity

10 pcs in one carton
